STAINLESSSTEEL WIRE MESH
Crimped Wire Mesh can be also known as the iron crimped mesh, stainless steel crimped mesh, black iron crimped mesh according to different materials.
Crimped Wire Mesh is made in a variety of materials through crimping mesh machine, a kind of universal wire products with square or rectangular openings.
Crimped Wire Mesh Material:
Iron wire, black wire, stainless steel wire, copper wire and other non-ferrous metal.
Crimped Wire Mesh Weaving:
Pre-crimping before Weaving. In two-way separated wave bending, locked bending, flat-topped curved, two-way bending, one-way separated wave bending.
Crimped Wire Mesh Features:
Structure firm and durable.
Crimped Wire Mesh Uses:
Used for mining, coal plants, construction, petrochemical industry, construction machinery,BBQ,etc.
Crimped Wire Mesh common specifications:
Diameter 1.0mm X mesh opening 8mm or 10mm
Diameter 1.5mm X mesh opening 12.5mm, 15mm or 20mm
Diameter 3mm X mesh opening 15mm, 20mm, 30mm
Length and width specifications: 1mX25m 1mX30m 1.2mX25m 1.2mX30m
| specifications | width (m) | length (m) | weight (kg/m 2 ) | |||
| mesh thickness(mm) | distance short(mm) | distance long(mm) | strip(mm) | |||
| 0.5 | 2.5 | 4.5 | 0.5 | 0.5 | 1 | 1.8 |
| 0.5 | 10 | 25 | 0.5 | 0.6 | 2 | 0.73 |
| 0.6 | 10 | 25 | 1 | 0.6 | 2 | 1 |
| 0.8 | 10 | 25 | 1 | 0.6 | 2 | 1.25 |
| 1 | 10 | 25 | 1.1 | 0.6 | 2 | 1.77 |
| 1 | 15 | 40 | 1.5 | 2 | 4 | 1.85 |
| 1.2 | 10 | 25 | 1.1 | 2 | 4 | 2.21 |
| 1.2 | 15 | 40 | 1.5 | 2 | 4 | 2.3 |
| 1.5 | 15 | 40 | 1.5 | 1.8 | 4 | 2.77 |
| 1.5 | 23 | 60 | 2.6 | 2 | 3.6 | 2.77 |
| 2 | 18 | 50 | 2.1 | 2 | 4 | 3.69 |
| 2 | 22 | 60 | 2.6 | 2 | 4 | 3.69 |
| 3 | 40 | 80 | 3.8 | 2 | 4 | 5.00 |
| 4 | 50 | 100 | 4 | 2 | 2 | 11.15 |
| 4.5 | 50 | 100 | 5 | 2 | 2.7 | 11.15 |
| 5 | 50 | 100 | 5 | 1.4 | 2.6 | 12.39 |
| 6 | 50 | 100 | 6 | 2 | 2.5 | 17.35 |
| 8 | 50 | 100 | 8 | 2 | 2.1 | 28.26 |
| Other specifications and size can be produced as buyers' requirements. | ||||||
COMPANY INFORMATION AND CERTIFICATE
Hebei Anjia Wire Net Weaving Co. LTD was founded in 1991, with a professional elite team, specialized in development and production. We have our own factory with area of 72,000 square meters, located in Anpin which is China"hometown of wire mesh", and factory area of 70,000 square meters in Guangzhou, we have strong production capacity and standard management, National Product Quality Inspection Register Certificate and Euro CE & RoHS quality certification, SGS certificate etc. All our products are based on ISO9001:2008 and ISO14001 standard.
